20L Reactor, Jacketed with Lifting Motor

The Goldleaf Scientific 20L Reactor with Electric Lift makes every reaction easier. This unique design allows separation of the body and lid of the reactor by simply pressing a button. Now you can easily access the reactor body and remove any solids, perform cleaning, or perform maintenance. These reactors greatly speed up your processing and pay for themselves by reducing downtimes. If access to the vessel is important to your reaction process, a Goldleaf 20L Reactor will remove the back pain from lab work.

The Goldleaf Scientific lifting 20l glass reactor is a versatile laboratory system mounted on a sturdy steel frame. Single or double jacketed options allow for precise control over temperature. Use a recirculating heater or chiller to maintain precise temperature parameters for your reactions. Connect your choice of vacuum pump to control pressure and vacuum depths, great for distillation or liquid transfer. Additional upgrades include PH sensors, oxygen sensors, ring baffles, full customization options. Includes a PTFE coated impeller with a high torque motor can stir and agitate your sample. The combination of controlled heating/cooling and agitation creates the perfect environment for a number of different reactions and chemical processes.

Goldleaf has spent countless hour developing our 20L Glass Reactors. Our in house glassblowing shop allows for nearly any type of customizations you need. Modifications to the glass body or lid, additional glassware pieces, and custom manifolds can be engineered and developed in house. Reach out to us directly for any questions about modifying your glass reactor setup via email at [email protected] or by phone at (510)487-1390.

20l Reactor Key Features:

• Lifting function on lid for easy access to inner vessel
• Articulating body for easy collection of solids
• Chemically resistant 3.3 Borosilicate glass vessel (single or double jacketed)
• Solid stainless steel frame
• Explosion proof upgrades available
• Customizable glassware and setup

Lifting reactors are ideal for working with solids and crystallizing material. For reactions working primarily with liquids, take a look at our 20L Non-lifting Reactor.

20l Reactor Applications:

• Liquid to liquid extraction (heptane/saline washes and pH scrubs)
• Solid and liquid mixing and extraction (absorbent scrubs, pH balancing, )
• Chemical reactions (CBD synthesis reactions, mixing terpenes into distillate)
• Homogenization and shearing (create stable emulsions, water soluble CBD, etc with ultrasonic)
• Bulk heating/cooling (degassing/decarbing, winterization, wiped film feed)
• Distillation (bulk solvent distillation with horizontal condensing system, residual solvent removal)

For a brief video of the reactor and its uses, click HERE.

Click HERE to Read our Full Guide on Glass Reactors.

UPGRADE to an Air Powered Motor or Explosion Proof electronics for use with flammable solvents

-Air Powered Motor (click for more info) operates via external air compressor so there are no electronics on the reactor skid

-Explosion Proof C1D2 Kit (click for more info) includes a sealed, C1D2 rated electric stirrer and control panel. Certified and safe for use with flammable solvents

For a brief video of the reactor and its uses, click HERE.

For information on how to select the proper ancillary equipment such as heater, chiller, and vacuum pumps, click HERE.

Click HERE to Read our Full Guide on Glass Reactors

Take a close up look at our pilot scale filter reactors in this video:

20L Reactor with Lifting Motor Specs:

Specs:
